ASE's Transition from Wafer to Panel Increases Semiconductor Output

Global AI Watch Editorial Team·AI-assisted··3 min read
ASE's Transition from Wafer to Panel Increases Semiconductor Output
Editorial Insight

Transitioning from wafers to panels could redefine semiconductor efficiency by 2027, impacting global supply chains.

Key Points

  • 1Third major shift in semiconductor packaging in a decade, post-3D ICs and fan-out.
  • 2Increases manufacturing complexity, requiring new equipment and processes.
  • 3Boosts domestic capabilities, reducing reliance on traditional wafer-based imports.

What Changed

ASE, a leading semiconductor packaging company, is making significant advancements by transitioning from wafer-based to panel-based packaging. Teck Chong Lee, ASE's technical director, highlighted that a 600mm panel can produce eight times more units than a 300mm wafer, showcasing a major efficiency leap (source). This shift addresses inefficiencies in wafer usage, especially with larger AI and HPC packages. The transition allows for better utilization of space, as panels can accommodate larger and more rectangular packages without the wastage typical of round wafers.

The change leverages the larger surface area of panels, which can fit more units per cycle compared to wafers. For instance, a 5.5×-reticle-size interposer produces 72 units on a full 600mm panel versus just 9 on a 300mm wafer (source). This not only improves output but also aligns with the growing demand for larger AI systems and packages.

While the transition is not entirely new, it marks a critical evolution in the semiconductor packaging landscape. The industry has traditionally relied on wafer-based processes, and this move highlights a shift in understanding and technology adaptation.

Strategic Implications

The shift from wafer to panel packaging has several strategic implications. For semiconductor manufacturers like ASE, this transition enhances production capabilities significantly, allowing them to meet the increasing demand for AI and HPC applications efficiently. This change could alter the competitive landscape, as companies that quickly adapt to panel-based processes may gain a significant advantage.

Moreover, this transition challenges existing manufacturing infrastructure, necessitating new equipment and processes. As Teck Chong Lee noted, the current infrastructure isn't fully ready for 600mm panels, indicating a need for investment in new technology and training (source). Companies that invest early in this technology could potentially dominate the market in the coming years.

Domestically, this shift increases national capabilities in semiconductor production, potentially reducing reliance on traditional wafer-based imports. This aligns with broader trends of enhancing technological sovereignty and reducing foreign dependencies.

What Happens Next

In the short term, companies like ASE are expected to invest in upgrading their manufacturing facilities to accommodate the new panel-based processes. This includes acquiring new equipment and developing processes that can handle the larger panel sizes. By mid-2027, companies that have successfully transitioned could see a substantial increase in their production capacity, aligning with the growing demand for AI and HPC packages.

Policy-wise, governments may look to support this transition through subsidies or incentives, recognizing the strategic importance of maintaining a competitive edge in semiconductor manufacturing. By late 2027, we might see national strategies incorporating panel-based technologies as a pillar for technological independence.

Second-Order Effects

This transition is likely to have significant effects on the semiconductor supply chain. Suppliers of wafer-based equipment may see a decline in demand, while manufacturers of panel-based technology could experience a surge in orders. This could lead to a shift in the balance of power among suppliers, with those aligned to panel technology gaining prominence.

Adjacent markets, such as equipment manufacturers and material suppliers, will need to adapt to this shift. Companies that can quickly pivot to meet the demands of panel-based manufacturing will likely thrive, while others may struggle to keep up.

Expert Perspective

In the broader context of sovereign AI, this transition represents a strategic move towards enhancing national capabilities in semiconductor production. By adopting panel-based packaging, countries can reduce their dependence on foreign wafer-based technologies, aligning with global trends towards technological independence.

This shift is similar to the transition seen with the adoption of 3D ICs and fan-out packaging in the past decade. Unlike those cases, the current transition involves a fundamental change in manufacturing processes and equipment, presenting both opportunities and challenges for the industry.
